bimetallic screw and barrels
| Price: |
215.0~5000.0 USD |
| Payment Terms: |
T/T,L/C,WU |
| Place of Origin: |
Zhejiang, China (Mainland) |
Product Detail
Model No.:
QY-S003
Production Capacity:
300 sets/month
Delivery Date:
within 25 days after order ...
Power:
4-150KW
Nitrided Case Depth:
0.45-0.7mm
Screw Straihgtness:
0.015mm
treatment:
Nitriding treatment
Nitriding time:
More Than 120 Hours
Warranty:
Common 1-2 years,bimetallic...
Means of Transport:
Ocean,Land,Air
Packing:
wooden case(export standard...
Brand Name:
QunYing
bimetallic screw and barrels:
bimetallic screw and barrel...
material:
38CrMoAlA(JIS SACM645)
Surface Roughness:
Ra0.4
Hardness of nitride layer:
HV850-1000
Nitrided Brittleness:
Less Than Grade 2
1.bimetallic screw and barrels of high quality
2.bimetallic screw and barrels of long operating life
3.ISO 9001:2008 approved
a bimetallic barrel is casted on the inwall with a 2-3mm alloy lay-out,which is wear-resisting\anti-corrosiveand anti-high-temperature.Its effective life has been highly improved compared with ordinary nitriding barrel.The bimetallic barrel is with particular speriority in processing engineering plastics\fluorinated plastic\polysulfone\PPO and other special plastic.Bimetallic alloy and welding method shall be varified according to all kinds of functional
screws and barrels.
Screw diameter:Φ15mm-Φ360mmL/D=15-56
According to different material and plastic products to design different screw structure ,compress rate and L/D!
According to different material and
plastic products to design different
Barrel with exhaust system and IKV force load system!
€Material & Processes of bimetallic screw and barrels
Alloy-steel of High-quality
1)38CrMoAlA
2)42CrMo
3)9Cr18MoV
4)CW6Mo5Cr4V2
5)Quality Duplex Stainless Steels
6)GH 113
7)Quality Powder Metallurgy Raw Materials
8)Cold/Thermal Spray Hard Metal process
9)Advanced nitriding Process
10)Corrosion & Abrasion Resistance Bimetal Spraying Process
€ technology Specification of bimetallic screw and barrels
1)heat-treatment
2)Nitriding treatment
3)Electroplate hard-chrome
4)high-frequency quenching
5)spraying corrosion wear-resisting dual metal layers
6)vacuum quenching
7)Surface Chromium-Plating's Hardness After Nitriding:≥900HB
8)Chrominm-plating Depth:0.05-0.10mm
9)Alloy Hardness:HRC50-65
10)Alloy Depth:0.8-2.0mm
As per customer's demand,we can also supply below:
PVC/
PE Film Blowing Screw;
Blow Molding Screw; PS/PE/PP/ABS
Sheet Extrusion Screw; PE Aluminum Plate;PPR Pipe Screw;EVA
Extrusion Screw;HDPE High efficiency Screw;PET Straps Screw;XPS/EPE Foamed Screw;Granulation Screw,Vented single screw etc.
if you have any inquiry, do not hesitate to inform us.
bimetallic screw and barrels has been presented above, want more similar products, please click bimetallic screw and barrels.
Our bimetallic screw and barrels is good in quality and competitive in price. We manufacture bimetallic screw and barrels and supply all size of
screw barrel according to your requirement.
| Technical Parameter |
| Base Material | 1)38CrMoAlA(JIS SACM645);2)Cr12MOV(JISSKD-11) ;
3)4Cr5MoSiV1(JIS SKD-61) ;4)42CrMo(AISI4140) |
| Bimetallic Alloy Materials | 1)Fe-based alloy2)Ni-based alloy/Deloroalloy
3)Co-based alloy4)NiCo-based alloy
5)Tungsten carbide/Wolframcarbide |
| Double-alloylevel | Level A - containing Tungsten of40%
Level B - containing tungsten of 25%
Level C - containing tungsten of15% |
| Surface Treatment | Heat Treatment
High FrequencyTreatment
Nitriding treatment(120Hours):
Depth of Nitrided Layer: 0.5-0.8mm
Hardness of Nitrided Layer: 900-1020Hv(HRC56°-65°)
HardChrome Plating treatment:
Thickness of Hard Chrome Plating Layer:0.05-0.10mm
Hardness ofHard Chrome Plating Layer: ≥950HV
Nickel alloyplating.treatment:
Bimetallic Barrel/Cylinder: Centrifugal Casting(Inlay Alloy)
BimetallicScrew: Plasma Alloy Coating Spraying
Depth of Bimetallic Layer: >2mm
Hardness of Bimetallic Layer: HRC55°-72°
Spraying corrosion wear-resisting dual metallayers |
| Basic information | Roughness of thesurface:Ra0.4um
Linearity of the screw: ≤0.015mm
Linear axis limit:≤0.02mm
Hardness afterHardening & Tempering: HB240-280
Fragility ofNitration:≤Twoclass |
| Material Application | 1)GeneralPlastics
2)ABS,PA,PC,PE,PET,PP,PS,EVA,PU,PVC,U-PVC,etc
3)PA + GF(GlassFiber)
4)Flame-resistant Reinforced Plastics
5)Modified EngineeringPlastics
6)All kinds of Mixed Recycled Material(in Scrap or Granule), PVC +30% CaCo3, etc |
